5754 aluminum plate belongs to Al-Mg-Si 5754 metal aluminum alloy (5000 series metal aluminum alloy), which has a wide range of applications in the high-end aluminum processing industry. With the vigorous development of the railway transportation market and the globalization of the automobile era, the processing demand for marine aluminum sheets, rail transit, and high-end automobile complex parts is increasing. Other than Aluminum Alloy 5754 Sheets & Plates contain components like iron, silicon, magnesium, zinc, copper, and chromium. As a result of these applications, these sheets show fantastic quality more prominent erosion opposition properties. It is additionally worked brilliantly in welding and bend applications. These sheets & plates have high machinability and usefulness quality.
| Standards | ASTM B209 / ASME SB209 |
|---|---|
| Thickness | 0.5 MM - 6.35 MM |
| Width | 500 - 3000 MM |
| Length | 2500 - 6000 MM |
| Finish | Mill, Customer Specific Finish |
| Type | Hot-Rolled (HR) / Cold-Rolled (CR) Sheet |
| Surface | Bright, polished, hair line, brush, sand blast, embossed, etching |
| Region / Standard | Equivalent |
|---|---|
| AA5754 | (USA) |
| ASTM B209 5754 | |
| UNS A95754 | |
| AMS 4017/4021 | |
| EN AW | 5754 |
| EN 573 | 3 |
| EN | |
| 485 | 2/4 (Europe) |
| ISO | AlMg3 |
| DIN 3.3535 | / Werkstoff AlMg3 (Germany) |
| BS 1470 | 5754 / |
| NG30 | |
| (UK) | |
| AFNOR A | G3 (France) |
| UNI 5754 | (Italy) |
| JIS H4000 | A5754 |
| JIS | H4040 |
| A5754 | H32/H34 |
| (Japan) | |
| GB/T 3190 | 5754 |
| A5754P (China) | |
| KS D6701 | 5754 (Korea) |
| TSE EN | 5754 |
| (Turkey) | |
| SANS EN 5754 | (South Africa) |
| NMX | H 5754 equivalent (Mexico) |
| IS 737 (India) | |
| **IS | |
| 52000 (India | |
| Rolled Aluminium Products Standard)** | |
| Hindalco 5754 | |
| Jindal 5754 (India OEM) | |
| Russian | |
| comparison: 5754 Russian equivalent | |
| 5754 AMg3 | |
| 5754 AMg2.5 | |
| GCC search | equivalents: |
| 5754 | |
| UAE grade | |
| 5754 Oman grade | |
| 5754 Saudi grade | |
H14 / H24 / H18 / T-O / T351 / T3 / T4 / T651 / T6 / H116 / H32 / H111
| UNS | EN | DIN | ISO | USA (AA) | WNR |
|---|---|---|---|---|---|
| A95754 | EN AW-5754 | AlMg3 | AlMg3 | AA5754 | 3.3535 |
| Element | % Present |
|---|---|
| Si | 0.4 |
| Fe | 0.4 |
| Mn | 0.5 |
| Mg | 2.6-3.2 |
| Al | Balance |
| Temper | H22 | H24 | H26 | 0/H111 |
|---|---|---|---|---|
|
Proof Stress 0.2% (MPa)
|
185
|
215
|
245
|
100
|
|
Tensile Strength (MPa)
|
245
|
270
|
290
|
215
|
|
Shear Strength (MPa)
|
150
|
160
|
170
|
140
|
|
Elongation A5 (%)
|
15
|
14
|
10
|
25
|
|
Hardness Vickers (HV)
|
75
|
80
|
85
|
55
|
| 1050 | 1060 | 1070 | 1100 | 2014 |
| 2017 | 2024 | 3003 | 5005 | 5052 |
| 5754 | 5083 | 5086 | 6061 | 6082 |
| 7050 | 7075 |
